Product Overview
CHEMI-CON EGXF500ELL102MU25S Electrolytic Capacitor, Miniature, 1000 µF, 50 V, ± 20%, Radial Leaded, 3000 hours @ 125°C, Polar
Product details
| Capacitance |
1000µF |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
3000 hours @ 125°C |
| Capacitor Case / Package |
- |
| Product Diameter |
14.5mm |
| Product Width |
- |
| Product Range |
GXF Series |
| Ripple Current |
2.48A |
| Operating Temperature Max |
125°C |
| SVHC |
No SVHC (07-Nov-2024) |
| Voltage(DC) |
50V |
| Capacitor Terminals |
Radial Leaded |
| Polarity |
Polar |
| Lead Spacing |
7.5mm |
| Product Length |
- |
| Product Height |
25mm |
| ESR |
0.031ohm |
| Operating Temperature Min |
-40°C |
| Qualification |
AEC-Q200 |
Other details
| Brand |
CHEMI-CON |
| Part Number |
EGXF500ELL102MU25S |
| Quantity |
Each |
| Technical Data Sheet (234.17KB) EN |
View or download |
