Product Overview
CHEMI-CON EKMS251VSN152MA40S Electrolytic Capacitor, 1500 µF, 250 V, ± 20%, Snap-In, 3000 hours @ 105°C
Product details
| Capacitance |
1500µF |
| Voltage(AC) |
- |
| Capacitor Terminals |
Snap-In |
| Polarity |
Polar |
| Product Diameter |
35mm |
| Lead Spacing |
10mm |
| Ripple Current |
3.48A |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (07-Nov-2024) |
| Voltage(DC) |
250V |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
3000 hours @ 105°C |
| Product Range |
KMS Series |
| Product Height |
40mm |
| ESR |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
Other details
| Brand |
CHEMI-CON |
| Part Number |
EKMS251VSN152MA40S |
| Quantity |
Each |
| Technical Data Sheet (246.43KB) EN |
View or download |
