Product Overview
CHEMI-CON EKHE401VSN122MA50Z Electrolytic Capacitor, 1210 µF, 400 V, ± 20%, Snap-In, 2000 hours @ 105°C
Product details
| Capacitance |
1210µF |
| Voltage(AC) |
- |
| Capacitor Terminals |
Snap-In |
| Polarity |
Polar |
| Product Diameter |
35mm |
| Lead Spacing |
10mm |
| Ripple Current |
2.78A |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (07-Nov-2024) |
| Voltage(DC) |
400V |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
2000 hours @ 105°C |
| Product Range |
KHE Series |
| Product Height |
50mm |
| ESR |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
Other details
| Brand |
CHEMI-CON |
| Part Number |
EKHE401VSN122MA50Z |
| Quantity |
Each |
| Technical Data Sheet (225.91KB) EN |
View or download |
