Product Overview
CHEMI-CON EKXJ251ELL151MK40S Electrolytic Capacitor, Miniature, 150 µF, 250 V, ± 20%, Radial Leaded, 12000 hours @ 105°C, Polar
Product details
| Capacitance |
150µF |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
12000 hours @ 105°C |
| Capacitor Case / Package |
- |
| Product Diameter |
12.5mm |
| Product Width |
- |
| Product Range |
KXJ Series |
| Ripple Current |
890mA |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (07-Nov-2024) |
| Voltage(DC) |
250V |
| Capacitor Terminals |
Radial Leaded |
| Polarity |
Polar |
| Lead Spacing |
5mm |
| Product Length |
- |
| Product Height |
40mm |
| ESR |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
AEC-Q200 |
Other details
| Brand |
CHEMI-CON |
| Part Number |
EKXJ251ELL151MK40S |
| Quantity |
Each |
| Technical Data Sheet (246.35KB) EN |
View or download |
