Product Overview
PANASONIC ECWFD2W335KC General Purpose Film Capacitor, Metallized PP, Radial Box - 2 Pin, 3.3 µF, ± 10%, 450 V
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
3.3µF |
| Voltage(AC) |
84V |
| Capacitor Mounting |
Through Hole |
| Humidity Rating |
- |
| Product Length |
25.3mm |
| Product Height |
14.6mm |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 10% |
| Voltage(DC) |
450V |
| Capacitor Terminals |
PC Pin |
| Lead Spacing |
22.5mm |
| Product Width |
9.8mm |
| Product Range |
ECWFD Series |
| Operating Temperature Max |
110°C |
| SVHC |
No SVHC (04-Feb-2026) |
