Product Overview
ANALOG DEVICES HMC788ACPSZ-EP-PT RF Amplifier, 10MHz to 10GHz, 14dB, 4.5V to 5.5V, -55°C to 105°C, LFCSP-EP
Product details
| Frequency Min |
10MHz |
| Gain |
14dB |
| Noise Figure Typ |
7dB |
| RF IC Case Style |
LFCSP-EP |
| Gain Typ |
14dB |
| Supply Voltage Min |
4.5V |
| IC Case / Package |
LFCSP-EP |
| Operating Temperature Min |
-55°C |
| Product Range |
- |
| Frequency Max |
10GHz |
| No. of Channels |
1Channels |
| Frequency Response RF Min |
10MHz |
| Frequency Response RF Max |
10GHz |
| Third Order Output Intercept Point OIP3 Typ |
33dBm |
| Supply Voltage Max |
5.5V |
| No. of Pins |
6Pins |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
ANALOG DEVICES |
| Part Number |
HMC788ACPSZ-EP-PT |
| Quantity |
Each |
| Technical Data Sheet (138.45KB) EN |
View or download |
