Product Overview
Also known as
76PI24704030J
Product details
| Dielectric Type |
Double Metallized PP |
| Capacitance |
0.047µF |
| Typical Applications |
High Frequency |
| Voltage(AC) |
400V |
| Humidity Rating |
GRADE II (Test Condition A) |
| Lead Spacing |
15mm |
| Peak Current |
141A |
| ESR |
0.014ohm |
| Product Length |
18mm |
| Product Height |
13.5mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-55°C |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
630V |
| Capacitor Terminals |
Radial Leaded |
| dv/dt Rating |
3kV/µs |
| RMS Current (Irms) |
100mA |
| Product Diameter |
- |
| Product Width |
7.5mm |
| Ripple Current |
5.4A |
| Product Range |
R76 Series |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
KEMET |
| Part Number |
R76PI24704030J |
| Quantity |
Each |
| Product Change Notice (467.38KB) EN |
View or download |
