Product Overview
MIKROE-6234 is a Click shield for Teensy 4.0 perfect solution for quickly and easily expanding the capabilities of the Teensy 4.0 host board with many Click boards™, enabling the creation of complex and unique projects. The Click Shield for Teensy 4.0 provides three mikroBUS™ sockets to add any functionality from our ever-growing range of Click boards™. We are fully stocked with everything, from sensors and Wi-Fi transceivers to motor control and audio amplifiers. Teensy 4.0 is a high-performance development board featuring a 600MHz ARM Cortex-M7 processor that brings many powerful CPU features to a true real-time microcontroller platform. The Cortex-M7 is a dual-issue superscalar processor, meaning the M7 can execute two instructions per clock cycle. Tightly Coupled Memory is a special feature that allows Cortex-M7 fast single-cycle access to memory using a pair of 64-bit wide buses. Teensy 4.0's Cortex-M7 processor includes a FPU that supports both 64-bit "double" and 32-bit "float".
- 2x mikroBUS™ sockets
- Connector for connecting compatible Teensy 4.0 board
- Four TXS0108E level-shifting voltage translators
- GND hook for testing purposes
- Analog, GPIO, I2C, PWM, SPI, UART interface
- mikroBUS, Teensy 4.0 compatibility
- 3.3V, 5V, external input voltage
Product details
| Silicon Manufacturer |
NXP |
| Core Sub-Architecture |
Cortex-M7F |
| Silicon Family Name |
i.MX RT |
| Kit Contents |
Click Shield MIKROE-6234 |
| SVHC |
No SVHC (27-Jun-2024) |
| Core Architecture |
ARM |
| Silicon Core Number |
iMXRT1062 |
| For Use With |
Mikroe Teensy 4.0 Host Board |
| Product Range |
- |
Other details
| Brand |
MIKROELEKTRONIKA |
| Part Number |
MIKROE-6234 |
| Quantity |
Each |
| Technical Data Sheet (3.12MB) EN |
View or download |
