Product Overview
Also known as
44AHGP6100ZA0J
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
100µF |
| Typical Applications |
Snubber |
| Voltage(AC) |
330V |
| Humidity Rating |
- |
| Lead Spacing |
35mm |
| Peak Current |
2kA |
| ESR |
5000µohm |
| Product Length |
- |
| Product Height |
135mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
| Capacitor Case / Package |
Can |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Stud Mount - M12 |
| Voltage(DC) |
600V |
| Capacitor Terminals |
Screw |
| dv/dt Rating |
20V/µs |
| RMS Current (Irms) |
- |
| Product Diameter |
76mm |
| Product Width |
- |
| Ripple Current |
32A |
| Product Range |
C44A Series |
| Operating Temperature Max |
85°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
KEMET |
| Part Number |
C44AHGP6100ZA0J |
| Quantity |
Each |
| Product Change Notice (467.38KB) EN |
View or download |
