Product Overview
Also known as
4ATHBW4330A3GJ
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
3.3µF |
| Typical Applications |
High Frequency |
| Voltage(AC) |
350V |
| Humidity Rating |
- |
| Lead Spacing |
27.5mm |
| Peak Current |
342A |
| ESR |
2400µohm |
| Product Length |
32mm |
| Product Height |
37mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
| Capacitor Case / Package |
Radial Box - 4 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
600V |
| Capacitor Terminals |
PC Pin |
| dv/dt Rating |
104V/µs |
| RMS Current (Irms) |
21A |
| Product Diameter |
- |
| Product Width |
22mm |
| Ripple Current |
25A |
| Product Range |
C4AT Series |
| Operating Temperature Max |
85°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
KEMET |
| Part Number |
C4ATHBW4330A3GJ |
| Quantity |
Each |
