Product Overview
SFSD016GN1PT1TB-I-5E-06P-SW3 is a PS-66u iShield camera series, a secure microSDHC/SDXC memory card. It features intended usage: drone camera, body camera, professional photography (DSLR), dash cam, surveillance camera, action camera, camera traps, and more.
- 16Gb capacity, 3D PSLC flash
- Host-agnostic plug-and-play solution for protecting data recorded on common cameras
- Hardware encryption (AES 256bit) and access protection integrated on the memory card
- Supports loop recording (e.g. in dashcams) without host modification
- Comes with user-friendly management tool (Windows, Linux, MacOS): iShield camera card tool (iCCT)
- 10 years at life begin / 1 year at life end data retention
- Standard microSD Memory card form factor - 15.0mm x 11.0mm x 0.7mm
- Fully compliant with SD Memory Card specification 5.0 and microSD Memory Card Addendum 4.00
- Operating voltage range from 2.7V to 3.6V
- Industrial temperature range from -40°C to 85°C
Product details
| Flash Memory Card Type |
MicroSDHC Card |
| Standard Speed Class |
Class 10 |
| Video Speed Class |
V30 |
| Supply Voltage Nom |
3.6V |
| Operating Temperature Max |
85°C |
| SVHC |
No SVHC (23-Jan-2024) |
| Memory Capacity |
16GB |
| UHS Standard |
UHS-I U1 |
| App Rating |
- |
| Operating Temperature Min |
-40°C |
| Product Range |
PS-66u iShield Archive Series |
Other details
| Brand |
SWISSBIT |
| Part Number |
SFSD016GN1PT1TB-I-5E-06P-SW3 |
| Quantity |
Each |
| Product Change Notice (76.96KB) EN |
View or download |
| Technical Data Sheet (120.80KB) EN |
View or download |
