Product Overview
Also known as
B32641B 223K
Product details
| Dielectric Type |
Double Metallized PP |
| Capacitance |
0.022µF |
| Typical Applications |
High Frequency |
| Voltage(AC) |
500V |
| Humidity Rating |
GRADE II (Test Condition A) |
| Lead Spacing |
10mm |
| Peak Current |
- |
| ESR |
0.044ohm |
| Product Length |
13mm |
| Product Height |
16mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-55°C |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 10% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
1kV |
| Capacitor Terminals |
Radial Leaded |
| dv/dt Rating |
6.2kV/µs |
| RMS Current (Irms) |
2.6A |
| Product Diameter |
- |
| Product Width |
7mm |
| Ripple Current |
- |
| Product Range |
B32641B Series |
| Operating Temperature Max |
125°C |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
