Product Overview
Also known as
1057657
Product details
| Sensor Type |
Distance Sensor |
| Sensing Distance Max |
35m |
| Supply Voltage DC Min |
12V |
| Output Type |
Analogue - 4 to 20mA / 0 to 10V, Digital - Push-Pull, PNP / NPN, IO-Link |
| Product Range |
Dx35 Series |
| Supply Voltage Min |
12VDC |
| Light Source |
658nm Red Laser |
| IP Rating |
IP65, IP67 |
| Operating Temperature Max |
55°C |
| Sensing Range Max |
35m |
| Sensing Method |
Reflective |
| Sensor Output Type |
Current / Voltage, NPN / PNP, Push Pull |
| Supply Voltage DC Max |
30V |
| Connection Method |
5 Pin M12 Connector |
| Supply Voltage Max |
30VDC |
| Qualification |
- |
| Operating Temperature Min |
-30°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
