Product Overview
Also known as
1125113
Product details
| Sensor Type |
Photoelectric Sensor |
| Sensing Range Max |
1.2m |
| Sensing Method |
Background/Foreground Suppression, MultiMode, Proximity |
| Supply Voltage DC Max |
30V |
| Product Range |
W12 Series |
| Supply Voltage Min |
10VDC |
| Light Source |
655nm Red Laser |
| IP Rating |
IP66, IP67, IP69 |
| Operating Temperature Max |
55°C |
| Sensing Distance Max |
1.2m |
| Supply Voltage DC Min |
10V |
| Sensor Output Type |
Push Pull, NPN / PNP |
| Output Type |
Complementary NPN / PNP, Push Pull |
| Connection Method |
4 Pin M12 Connector |
| Supply Voltage Max |
30VDC |
| Qualification |
- |
| Operating Temperature Min |
-20°C |
| SVHC |
No SVHC (04-Feb-2026) |
