Product Overview
Also known as
1037248
Product details
| Encoder Technology |
Mechanical |
| Encoder Resolution |
512PPR |
| Orientation |
Horizontal |
| Encoder Output |
HTL/TTL |
| Product Range |
DFS60 Series |
| Rotational Life Cycles |
36000000000 |
| Shaft Type |
Solid Shaft |
| Shaft Diameter |
6mm |
| Supply Voltage Max |
32V |
| Operating Temperature Max |
100°C |
| Termination |
M23/12 Pin Connector |
| Encoder Type |
Incremental |
| No. of Detents |
- |
| Push Switch |
- |
| Encoder Mounting |
Flange Mount |
| Rotational Speed Max |
9000rpm |
| No. of Channels |
6Channels |
| Shaft Length |
10mm |
| Supply Voltage Min |
10V |
| Operating Temperature Min |
-40°C |
| IP Rating |
IP65, IP67 |
| SVHC |
No SVHC (04-Feb-2026) |
