Description
Product Overview
The BD233 is an NPN silicon power transistor designed for high-current and high-power applications. It is widely used in electronic circuits such as power amplifiers, switching regulators, and motor controllers due to its robust performance and excellent electrical characteristics. The BD233 transistor is a versatile and reliable component for various high-power applications, offering robust performance and ease of use for engineers and hobbyists alike.
- Collector-Emitter Voltage (Vceo): 100V
- Collector-Base Voltage (Vcbo): 100V
- Emitter-Base Voltage (Vebo): 5V
- Collector Current (Ic): 4A
- Base Current (Ib): 1A
- Power Dissipation (Pd): 40W
- DC Current Gain (hFE): 25-125 at Ic = 1A, Vce = 2V
- Package Type: TO-220
- Pin Configuration: 3 Pins (Collector, Base, Emitter)
- Mounting Style: Through-Hole
- Junction Temperature (Tj): -65°C to +150°C
- Thermal Resistance, Junction to Case (RθJC): 3.12°C/W
Applications
Audio, Power Supplies, DC/DC Converters, Motor Drive & Control, Signal Processing
Product details
| Transistor Polarity | NPN |
| Continuous Collector Current | 2A |
| Transistor Case Style | TO-126 |
| No. of Pins | 3Pins |
| DC Current Gain hFE Min | 25hFE |
| Product Range | Multicomp Pro Bipolar Transistor NPN |
| MSL | - |
| Collector Emitter Voltage Max | 45V |
| Power Dissipation | 50W |
| Transistor Mounting | Through Hole |
| Transition Frequency | 3MHz |
| Operating Temperature Max | 150°C |
| Qualification | - |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | MULTICOMP PRO |
| Part Number | BD233 |
| Quantity | Each |
| Technical Data Sheet (1.18MB) EN | View or download |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 124.98 |
| 3-5 | ₹ 123.7 |
| 5-10 | ₹ 121.15 |
| 10+ | ₹ 118.6 |
Bulk discount will be automatically applied during checkout based on quantity.
