Description
Product Overview
The BD132 is an PNP single bipolar transistor housed in a TO-126 package. It features a collector-emitter voltage of 45V, continuous collector current of 3A, a transition frequency of 60 MHz, and a DC current gain of 40. With a power dissipation capability of 15W, it is ideal for medium power applications such as audio amplifiers, power supplies, switching circuits, and motor drivers.
- Collector Base Voltage: 45V
- Collector Emitter Voltage: 45V
- Emitter Base Voltage: 6V
- Collector Current Continuous: 3A
- Total Device Dissipation: 15W
- Junction Temperature: 150°C
- DC Current Gain: 40
- Transition Frequency: 60MHz
Applications
Audio, Power Supplies, DC/DC Converters, Motor Drive & Control, Signal Processing
Product details
| Transistor Polarity | PNP |
| Continuous Collector Current | 3A |
| Transistor Case Style | TO-126 |
| No. of Pins | 3Pins |
| DC Current Gain hFE Min | 20hFE |
| Product Range | Multicomp Pro Bipolar Transistor PNP |
| MSL | - |
| Collector Emitter Voltage Max | 45V |
| Power Dissipation | 15W |
| Transistor Mounting | Through Hole |
| Transition Frequency | 60MHz |
| Operating Temperature Max | 150°C |
| Qualification | - |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | MULTICOMP PRO |
| Part Number | BD132 |
| Quantity | Each |
| Technical Data Sheet (185.14KB) EN | View or download |
