Product Overview
25-300-3000-PSI is a 300 series dial indicating pressure gauge. It is ideal for applications including automotive, construction, hydraulics & pneumatics, mining, stamping & forming presses and transportation.
- High quality, heavy-duty liquid filled gauge
- 2-1/2″ gauge size
- Brass case with bottom connection
- Pressure range from 0psi to 3000psi
- ±1.6% full scale accuracy
- Single scale psi option, die cast brass case with natural brass finish
- Aluminium, white background with black scale, UV resistant
- Acrylic with o-ring seal lens and balanced aluminium, black finish pointer
- Temperature ambient media -4°F to 140°F (-20°C to 60°C), ambient 0°F to 160°F (-18°C to 71°C)
- Copper alloy coiled safety tube
Product details
| Thread Size - Metric |
- |
| Operating Temperature Min |
-18°C |
| Product Range |
300 Series |
| Operating Pressure Max |
3000psi |
| Operating Temperature Max |
71°C |
| SVHC |
To Be Advised |
Other details
| Brand |
NOSHOK |
| Part Number |
25-300-3000-PSI |
| Quantity |
Each |
| Technical Data Sheet (649.59KB) EN |
View or download |
