Product Overview
20-110-30-PSI/BAR is a 100 series dial indicating pressure gauge. It is ideal for applications including hydraulics, pneumatics, medical, pumps, compressors, refrigeration controls and more.
- General purpose non-fillable dry gauge
- 2″ gauge size
- ABS case with back connection
- Pressure ranges from 0psi to 30psi
- ±2.5% full scale accuracy
- Dual scale psi/bar option
- White background with black primary scale & red secondary scale, UV resistant
- Acrylic lens and moulded plastic pointer
- Temperature media -4°F to 140°F (-20°C to 60°C), ambient -40°F to 140°F (-40°C to 60°C)
- Copper alloy Bourdon tube measuring element
Product details
| Thread Size - Metric |
- |
| Operating Temperature Min |
-40°C |
| Product Range |
100 Series |
| Operating Pressure Max |
30psi |
| Operating Temperature Max |
60°C |
| SVHC |
To Be Advised |
Other details
| Brand |
NOSHOK |
| Part Number |
20-110-30-PSI/BAR |
| Quantity |
Each |
| Technical Data Sheet (697.71KB) EN |
View or download |
