Product Overview
653-500-1-1-2-36 is a 653 series pressure transmitter & transducer. Ideal for applications including hydraulics & pneumatics, automotive, pumps & compressors, refrigeration controls and transportation.
- Pressure range from 0psig to 500psig
- ±0.5% full scale (BFSL)
- 4mA to 20mA, 2-wire
- 1/4″ NPT male connection
- 18″ integral cable IP67
- For static and dynamic load measurements
- No internal sealing elements
- Stainless steel wetted parts
- Piezoresistive silicon chip
- Compact size
Product details
| Pressure Type |
Gauge |
| Sensor Output Type |
Analogue |
| Pressure Measurement Type |
Gauge |
| Voltage Rating |
36VDC |
| Pressure Port Size |
1/4" |
| Supply Voltage Min |
12VDC |
| Media Type |
Air, Hydraulic Fluid, Oil, Water |
| Operating Temperature Min |
-20°C |
| Product Range |
653 Series |
| Pressure Port Type |
NPT Male |
| Operating Pressure Min |
0psi |
| Operating Pressure Max |
500psi |
| Port Style |
1/4" MNPT |
| Transducer Connection / Termination |
Cable |
| Supply Voltage Max |
36VDC |
| Output Interface |
- |
| Housing Material |
304 Stainless Steel |
| Operating Temperature Max |
85°C |
| SVHC |
Lead (04-Feb-2026) |
