Product Overview
JAC-40-683 is a JAC series power line filter. It is a compact and low profile, common mode EMI/EMC filter in 150KHz to 1MHz. Approved by UL1283, CSA C22.2 No.8 (C-UL), DIN EN60939 VDE0565 Teil3-1, ENEC safety approval.
- Three phase input type (1-stage filter)
- Rated voltage of 500VAC, rated current of 40A
- Test voltage of 2,500VAC (cut-off current = 100mA), 1minute at room temperature & humidity
- Isolation resistance (terminal-mounting plate) of 500VDC 100Mohm min at room temperature & humidity
- DC resistance of 7mohm maximum
- Leakage current 250/500V 60Hz of 2.5mA/5mA maximum
- Operating temperature range from -40 to +85°C
- Case size (without projection) of 65 x 54 x 153mm (W x H x D)
Product details
| Filter Applications |
General Purpose |
| Current Rating |
40A |
| No. of Stages |
1 Stage |
| Filter Input Terminals |
Screw |
| Product Range |
JAC Series |
| Voltage Rating |
500VAC |
| No. of Phases |
Three Phase |
| Filter Mounting |
Chassis Mount |
| Filter Output Terminals |
Screw |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
COSEL |
| Part Number |
JAC-40-683 |
| Quantity |
Each |
| Technical Data Sheet (388.99KB) EN |
View or download |
