Product Overview
MHFS64805 is a MHFS6 series PCB mount DC to DC converter in an industry standard 8 pin SIP package. It features include built-in overcurrent protection circuits (recovers automatically) and built-in remote ON/OFF. Approved by UL62368-1, EN62368-1, C-UL (equivalent to CAN/CSA-C22.2 No.62368-1), ANSI/AAMI ES60601-1, EN60601-1 3rd, C-UL (equivalent to CAN/CSA-C22.2 No.60601-1) safety approval.
- Input voltage range from 18V to 76V
- Maximum output power of 6W
- Output voltage of 5V, output current of 1.2A
- I/O isolation voltage of 3,000VAC (1 minute), 4,200VDC (1 minute)
- Output voltage adjustability by external variable resistor
- For medical electric equipment (ANSI/AAMI ES60601-1, EN60601-1 3rd), medical isolation grade 2MOOP
- High reliability : not built-in aluminium and tantalum electrolytic capacitor
- Operating temperature/humidity of -40 to +85℃, 20 to 95%RH (non condensing) (required derating)
- Case size of 26.0 x 12.0 x 9.5mm (W x H x D)
- Up to 5 year warranty
Product details
| Power Supply Applications |
ITE & Medical |
| Input Ratio |
4:1 |
| No. of Outputs |
1 Output |
| Output Current - Output 1 |
1.2A |
| Output Current - Output 2 |
- |
| Isolation Voltage |
4.2kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
12mm |
| Input Voltage DC Min |
18V |
| Product Range |
MHFS6 Series |
| DC / DC Converter Type |
SIP |
| Output Power Max |
6W |
| Output Voltage - Output 1 |
5V |
| Output Voltage - Output 2 |
- |
| Output Regulation |
- |
| Input Voltage DC Nom |
48V |
| Width |
9.5mm |
| Depth |
26mm |
| Input Voltage DC Max |
76V |
| SVHC |
Lead (04-Feb-2026) |
Other details
| Brand |
COSEL |
| Part Number |
MHFS64805 |
| Quantity |
Each |
| Technical Data Sheet (1.65MB) EN |
View or download |
