Product Overview
MGXW1R52412 is a MGXW1R5 series PCB mount DC-DC converter in an industry standard 6 pin SIP package. It features include built-in overcurrent protection circuits (recovers automatically).
- Input voltage range from 6V to 60V
- Output power of 1.56W
- Output voltage of ±12V, output current of 65mA/65mA
- I/O isolation voltage DC1,500V (1 minute)
- High reliability : not built-in aluminium and tantalum electrolytic capacitor
- Operating temperature/humidity of -40 to +85℃, 20 to 95%RH (non condensing) (required derating)
- UL60950-1, C-UL, EN62368-1 safety approvals
- Case size of 17.0 x 12.0 x 8.5mm (W x H x D)
- 10 year warranty
Product details
| Power Supply Applications |
ITE |
| Input Ratio |
10:1 |
| No. of Outputs |
2 Output |
| Output Current - Output 1 |
65mA |
| Output Current - Output 2 |
65mA |
| Isolation Voltage |
1.5kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
12mm |
| Input Voltage DC Min |
6V |
| Product Range |
MGXW1R5 Series |
| DC / DC Converter Type |
SIP |
| Output Power Max |
1.56W |
| Output Voltage - Output 1 |
12V |
| Output Voltage - Output 2 |
-12V |
| Output Regulation |
- |
| Input Voltage DC Nom |
24V |
| Width |
8.5mm |
| Depth |
17mm |
| Input Voltage DC Max |
60V |
| SVHC |
Lead (04-Feb-2026) |
Other details
| Brand |
COSEL |
| Part Number |
MGXW1R52412 |
| Quantity |
Each |
| Technical Data Sheet (6.36MB) EN |
View or download |
