Product Overview
FFPC-0.3-12-8 is a FFPC series flexible ferrite core. The flexible ferrite sheet is a noise filter made from a specially sintered material with reduced thickness, specifically designed for FPCs. It provides a significant advantage over traditional rigid and brittle ferrites. It helps prevent internal interference caused by radiated noise generated from FPC cable use in DSCs, DVCs, and laptops.
- Optimum EMC solution for FPCs and FFCs
- Higher insertion loss in low frequencies compared to standard EMI absorbers
- Excellent noise suppression
- PET with adhesive layer, double-sided adhesive tape
- Applicable cable width of 12mm
- 12 x 8 x 0.3mm size
Product details
| Impedance |
- |
| Frequency Max |
300MHz |
| SVHC |
No SVHC (25-Jun-2025) |
| Frequency Min |
30MHz |
| Product Range |
SMARTPLY FFPC Series |
Other details
| Brand |
KGS KITAGAWA |
| Part Number |
FFPC-0.3-12-8 |
| Quantity |
Each |
| Technical Data Sheet (227.92KB) EN |
View or download |
