Product Overview
WURTH ELEKTRONIK 875115452003 Polymer Aluminium Electrolytic Capacitor, 100 µF, 20 V, Radial Can - SMD, 0.02 mohm
Product details
| Capacitance |
100µF |
| Capacitor Case / Package |
Radial Can - SMD |
| Lifetime @ Temperature |
2000 hours @ 105°C |
| Capacitor Mounting |
Surface Mount |
| Ripple Current |
3.5A |
| Product Length |
- |
| Product Height |
8.7mm |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (04-Feb-2026) |
| Voltage(DC) |
20V |
| ESR |
0.02mohm |
| Capacitance Tolerance |
± 20% |
| Capacitor Terminals |
Solder |
| Product Diameter |
8mm |
| Product Width |
- |
| Operating Temperature Min |
-55°C |
| Product Range |
WCAP-PSHP Series |
Other details
| Brand |
WURTH ELEKTRONIK |
| Part Number |
875115452003 |
| Quantity |
Each |
| Technical Data Sheet (756.76KB) EN |
View or download |
