Product Overview
Also known as
4GAMUD4150AA1J
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
1.5µF |
| Typical Applications |
AC Filter |
| Voltage(AC) |
450V |
| Humidity Rating |
- |
| Lead Spacing |
- |
| Peak Current |
210A |
| ESR |
3500µohm |
| Product Length |
- |
| Product Height |
44mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
| Capacitor Case / Package |
Axial Leaded |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
850V |
| Capacitor Terminals |
PC Pin |
| dv/dt Rating |
140V/µs |
| RMS Current (Irms) |
- |
| Product Diameter |
24.5mm |
| Product Width |
- |
| Ripple Current |
12A |
| Product Range |
C4G Series |
| Operating Temperature Max |
85°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
KEMET |
| Part Number |
C4GAMUD4150AA1J |
| Quantity |
Each |
| Product Change Notice (267.37KB) EN |
View or download |
