Product Overview
Type P-M style closed ended immersion sensor for use where the sensors will be immersed in a fluid.
- Pt100 sensor
- Class A sensor accuracy
- PFA insulated & jacketed w/shield (250°C max)
- 4-wire PVC cable 2' long with stripped leads
- No mounting thread
- 50mm sheath diameter
Product details
| RTD Type |
Probe with Leads |
| RTD Accuracy |
Class A |
| Resistance |
50ohm |
| Measured Temperature Max |
250°C |
| RTD Element Material |
Platinum |
| Probe Diameter |
6mm |
| Cable Length - Metric |
2m |
| Cable Termination |
Wire Leaded |
| Product Range |
P-M Series |
| Sensing Temperature Min |
-100°C |
| Sensing Temperature Max |
250°C |
| Measured Temperature Min |
-100°C |
| Resistance @ 0°C |
50ohm |
| Probe Material |
- |
| Probe Length |
50mm |
| Cable Length - Imperial |
6.6ft |
| Wire Configuration |
4-Wire |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
OMEGA |
| Part Number |
P-M-A-6-50-0-TS-2 |
| Quantity |
Each |
| Technical Data Sheet (546.21KB) EN |
View or download |
