Product Overview
Also known as
395300012, 395300012, 39530-0012
Product details
| Pitch Spacing |
5.08mm |
| No. of Positions |
12Ways |
| Connector Type |
Terminal Block, Eurostyle |
| Connector Mounting |
Cable Mount |
| Wire Connection Method |
Screw |
| Rated Voltage |
300V |
| Contact Material |
Phosphor Bronze |
| SVHC |
Lead (04-Feb-2026) |
| No. of Contacts |
12Contacts |
| Wire Size AWG Min |
26AWG |
| Wire Size AWG Max |
12AWG |
| Conductor Area CSA |
3.31mm² |
| Rated Current |
18A |
| Contact Plating |
Tin Plated Contacts |
| Product Range |
Eurostyle 39530 Series |
