Product Overview
TMR 12-4813WI is a TMR 12WI series isolated 12W DC/DC converter module with regulated output, featuring wide 4:1 input voltage range. The product offers a very high power density of 4.73W/cm³ in an ultra-compact SIP-8 metal package occupying only 2.0cm² (0.3 square inch) of board space. An excellent efficiency allows for an extended operating temperature range of -40° to +65°C without derating under natural convection conditions. Further features include remote on/Off control, continuous short circuit protection and an I/O isolation voltage of 1600V DC. The very compact dimension of this converter makes it an ideal solution for many space critical applications in communication equipment, instrumentation and industrial electronics.
- 18 to 75V DC (48V DC nominal) input voltage range
- 15V DC output voltage, 800mA output current, 89% typical efficiency
- High efficiency for low thermal loss
- Operating temperature range from -40°C to +85°C
- Fully regulated outputs
- Indefinite short circuit protection, undervoltage lockout, output current limitation
- 3-year product warranty
- Complies with EN 62368-1, IEC 62368-1, UL 62368-1 standards
- Copper housing, silicone (UL 94 V-0 rated) potting, tinned copper pin material
- Natural convection (20LFM) cooling system
Product details
| Power Supply Applications |
ITE |
| Input Ratio |
4:1 |
| No. of Outputs |
1 Output |
| Output Current - Output 1 |
800mA |
| Output Current - Output 2 |
- |
| Isolation Voltage |
1.6kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
12mm |
| Input Voltage DC Min |
18V |
| Product Range |
TMR 12WI Series |
| DC / DC Converter Type |
SIP |
| Output Power Max |
12W |
| Output Voltage - Output 1 |
15V |
| Output Voltage - Output 2 |
- |
| Output Regulation |
Regulated |
| Input Voltage DC Nom |
48V |
| Width |
9.6mm |
| Depth |
22mm |
| Input Voltage DC Max |
75V |
| SVHC |
Lead (04-Feb-2026) |
Other details
| Brand |
TRACO POWER |
| Part Number |
TMR 12-4813WI |
| Quantity |
Each |
| CAD Multiple Formats (48.57KB) EN |
View or download |
| Technical Data Sheet (903.26KB) EN |
View or download |
