Product Overview
MP008047 is the highest-rated in the series, holding 15A and tripping at 28A. It offers strong protection for large power systems and automatically resets after fault clearance.
- UL approved
- Resettable overcurrent protection for extended component life
- Fast trip response to safeguard sensitive circuits
- Compact radial design for easy PCB integration
- Wide operating temperature range from –40°C to +125°C
- Ideal for low-voltage DC applications like power supplies, batteries, and motors
Product details
| Product Range |
MP FHT |
| Holding Current |
15A |
| Time to Trip |
20s |
| Current Rating Max |
100A |
| Diameter |
- |
| Thickness |
3.6mm |
| Operating Temperature Min |
-40°C |
| Automotive Qualification Standard |
- |
| Voltage Rating |
16VDC |
| Trip Current |
28A |
| Fuse Shape |
Rectangular |
| Lead Spacing |
10.2mm |
| Length |
23.5mm |
| Height |
28.7mm |
| Operating Temperature Max |
125°C |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MP008047 |
| Quantity |
Each |
| Technical Data Sheet (283.02KB) EN |
View or download |
