Product Overview
The Phoenix Contact 1050769 is a SUNCLIX series female (socket) crimp contact designed for photovoltaic (PV) connector systems. Engineered for robust DC connections, it accommodates conductor cross sections from 2.5mm² to 4mm² (AWG 14–12) and is rated for 27A, making it well suited for solar installations and power distribution environments. The rolled socket construction ensures a secure mechanical and electrical interface, while the crimp termination complies with IEC 60352, guaranteeing consistent, reliable performance. Manufactured from copper based materials with a silver finish appearance, the 1050769 offers durability and long service life within SUNCLIX connector assemblies.
- Ideal for professional solar installation, system assembly, and maintenance
- Compatible with Phoenix Contact SUNCLIX PV connectors
- SUNCLIX series female (socket) crimp contact for photovoltaic connector systems
- Supports wire cross sections 2.5mm² to 4mm² (AWG 14–12)
- Rated 27A, suitable for solar DC applications and power distribution
- Crimp termination in accordance with IEC 60352 for secure electrical joints
- Rolled socket construction for strong mechanical engagement
- Durable copper based contact material with a silver finish appearance
Product details
| Product Range |
Sunclix |
| Contact Termination Type |
Crimp |
| Wire Size AWG Min |
14AWG |
| Contact Plating |
Silver Plated Contacts |
| SVHC |
No SVHC (04-Feb-2026) |
| Contact Gender |
Socket |
| Wire Size AWG Max |
12AWG |
| For Use With |
Phoenix Contact Sunclix Series Photovoltaic Connector |
| Contact Material |
Copper |
