Description
Product Overview
The 1714955 is a 2-position 6.35mm PCB Terminal Block with 6mm² cross-section, 24 to 10AWG wire size and soldering mounting. Through hole right angle block orientation and screw connection.
- 0° Conductor/PCB connection direction
- Green colour
- Terminal block bases can be mounted side by side to create any number of positions
- UL94V-0 Flammability rating
- M3 Screw thread
Applications
Industrial
Product details
| Pitch Spacing | 6.35mm |
| Wire Size AWG Min | 24AWG |
| Conductor Area CSA | 6mm² |
| Rated Current | 32A |
| Block Orientation | Through Hole Right Angle |
| SVHC | No SVHC (04-Feb-2026) |
| No. of Positions | 2Ways |
| Wire Size AWG Max | 10AWG |
| Wire Connection Method | Screw |
| Rated Voltage | 630V |
| Product Range | MKDS |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1714955 |
| Quantity | Each |
| Technical Data Sheet (143.16KB) EN | View or download |
