Product Overview
VISHAY MKP385322016JBM2B0 Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 0.022 µF, ± 5%, Through Hole
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
0.022µF |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
160V |
| Capacitor Terminals |
PC Pin |
| Product Length |
7.2mm |
| Product Height |
7mm |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 5% |
| Voltage(AC) |
110V |
| Humidity Rating |
GRADE II (Test Condition A) |
| Lead Spacing |
5mm |
| Product Width |
3.5mm |
| Product Range |
MKP385 Series |
| Operating Temperature Max |
110°C |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
VISHAY |
| Part Number |
MKP385322016JBM2B0 |
| Quantity |
Each |
| Product Change Notice (75.07KB) EN |
View or download |
| Technical Data Sheet (133.00B) EN |
View or download |
