Product Overview
MULTICOMP PRO MP004177 Power Film Capacitor, Metallized PP, Axial Leaded, 1 µF, ± 10%, Snubber, Through Hole
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
1µF |
| Typical Applications |
Snubber |
| Voltage(AC) |
500V |
| Humidity Rating |
- |
| Lead Spacing |
- |
| Peak Current |
700A |
| ESR |
4000µohm |
| Product Length |
54mm |
| Product Height |
- |
| Output (kvar) |
- |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
| Capacitor Case / Package |
Axial Leaded |
| Capacitance Tolerance |
± 10% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
1.2kV |
| Capacitor Terminals |
PC Pin |
| dv/dt Rating |
700V/µs |
| RMS Current (Irms) |
16.2A |
| Product Diameter |
- |
| Product Width |
30mm |
| Ripple Current |
- |
| Product Range |
MP SI Series |
| Operating Temperature Max |
85°C |
| SVHC |
To Be Advised |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MP004177 |
| Quantity |
Each |
| Technical Data Sheet (511.30KB) EN |
View or download |
