Product Overview
MULTICOMP PRO MP004110 Power Film Capacitor, Metallized PP, 0.33 µF, ± 10%, Induction Heating, Resonant Power Supplies
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
0.33µF |
| Typical Applications |
Induction Heating, Resonant Power Supplies |
| Voltage(AC) |
700V |
| Humidity Rating |
- |
| Lead Spacing |
5mm |
| Peak Current |
- |
| ESR |
1000µohm |
| Product Length |
75mm |
| Product Height |
50mm |
| Output (kvar) |
150kvar @ 100 to 145kHz |
| Operating Temperature Min |
- |
| Qualification |
- |
| Capacitor Case / Package |
Axial Leaded |
| Capacitance Tolerance |
± 10% |
| Capacitor Mounting |
Panel Mount |
| Voltage(DC) |
- |
| Capacitor Terminals |
Screw |
| dv/dt Rating |
- |
| RMS Current (Irms) |
500A |
| Product Diameter |
65mm |
| Product Width |
30.2mm |
| Ripple Current |
- |
| Product Range |
MP SP Series |
| Operating Temperature Max |
85°C |
| SVHC |
To Be Advised |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MP004110 |
| Quantity |
Each |
| Technical Data Sheet (1.14MB) EN |
View or download |
