Product Overview
MULTICOMP PRO MP004105 Power Film Capacitor, Metallized PP, 1.32 µF, ± 10%, Induction Heating, Resonant Power Supplies
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
1.32µF |
| Typical Applications |
Induction Heating, Resonant Power Supplies |
| Voltage(AC) |
600V |
| Humidity Rating |
- |
| Lead Spacing |
5mm |
| Peak Current |
- |
| ESR |
0.0003ohm |
| Product Length |
56mm |
| Product Height |
66mm |
| Output (kvar) |
300kvar @ 100 to 170kHz |
| Operating Temperature Min |
- |
| Qualification |
- |
| Capacitor Case / Package |
Axial Leaded |
| Capacitance Tolerance |
± 10% |
| Capacitor Mounting |
Panel Mount |
| Voltage(DC) |
- |
| Capacitor Terminals |
Screw |
| dv/dt Rating |
- |
| RMS Current (Irms) |
650A |
| Product Diameter |
65mm |
| Product Width |
30.2mm |
| Ripple Current |
- |
| Product Range |
MP SP Series |
| Operating Temperature Max |
85°C |
| SVHC |
To Be Advised |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MP004105 |
| Quantity |
Each |
| Technical Data Sheet (1.85MB) EN |
View or download |
