Product Overview
Type CRG series is a thick film chip resistor. The resistive element is screen printed and fired, and a passivation layer added. Each resistor is trimmed to tolerance by laser. The pre-scribed tile is then broken into strips, the end plating fired on, and the strips broken into individual components. Final termination finish is electroplated matte Sn over a Ni barrier layer.
- High power to size ratio, ideally suited to industrial and general purpose use
- Temperature range from -55°C to 155°C
Product details
| Resistance |
33kohm |
| Power Rating |
100mW |
| Resistor Technology |
Thick Film |
| Product Range |
CRG Series |
| Voltage Rating |
75V |
| Product Width |
0.85mm |
| Operating Temperature Max |
155°C |
| SVHC |
No SVHC (04-Feb-2026) |
| Resistance Tolerance |
± 1% |
| Resistor Case / Package |
0603 [1608 Metric] |
| Resistor Type |
General Purpose |
| Temperature Coefficient |
± 100ppm/°C |
| Product Length |
1.6mm |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
Other details
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
![TE CONNECTIVITY - NEOHM CRG0603F33K SMD Chip Resistor, 33 kohm, ± 1%, 100 mW, 0603 [1608 Metric], Thick Film, General Purpose](http://www.tanotis.com/cdn/shop/files/2331442-40_e60ec037-b542-4fe1-a898-09ca69921872_{width}x.jpg?v=1791688754)
