Product Overview
TELEMECANIQUE SENSORS XS630B1MBL5 Inductive Proximity Sensor, Cylindrical, OsiSense XS, M30, 15 mm, SPST-NC, 20-264V, Pre-wired, 5m
Product details
| Sensor Type |
Inductive Proximity Sensor |
| Operating Temperature Max |
70°C |
| Thread Size - Metric |
M30 |
| Sensor Output Type |
SPST-NC |
| Supply Voltage DC Min |
24V |
| Supply Voltage Min |
24VDC |
| Sensor Terminals |
Cable |
| IP Rating |
IP68, IP69K |
| Product Range |
XS Series |
| Sensing Range Max |
15mm |
| Sensing Distance Min |
- |
| Sensing Distance Max |
- |
| Sensing Distance Nom |
15mm |
| Supply Voltage DC Max |
240V |
| Supply Voltage Max |
240VDC |
| Sensor Case / Package |
Cylindrical M30 Thread |
| Sensor Body Material |
Brass |
| Operating Temperature Min |
-25°C |
| SVHC |
To Be Advised |
Other details
| Brand |
TELEMECANIQUE SENSORS |
| Part Number |
XS630B1MBL5 |
| Quantity |
Each |
| Certificate of Conformity (1.06MB) EN |
View or download |
