Product Overview
NIDEC COMPONENTS ST-4ETA501 Trimmer, Single Turn, RuO2 Cermet, Top Adjust, 500 ohm, Surface Mount, 1 Turns
Product details
| Trimmer Type |
Single Turn |
| Adjustment Type |
Top Adjust |
| Potentiometer Mounting |
Surface Mount |
| Product Range |
ST-4 Series |
| Resistance Tolerance |
± 20% |
| Trimmer Shape / Size |
Rectangular |
| Product Length |
5mm |
| Product Height |
2.3mm |
| Operating Temperature Max |
125°C |
| SVHC |
To Be Advised |
| Element Material |
RuO2 Cermet |
| Track Resistance |
500ohm |
| No. of Turns |
1Turns |
| Power Rating |
250mW |
| Temperature Coefficient |
± 100ppm/°C |
| Resistor Case / Package |
SMD |
| Product Width |
4.5mm |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
Other details
| Brand |
NIDEC COMPONENTS |
| Part Number |
ST-4ETA501 |
| Quantity |
Each |
| Technical Data Sheet (795.89KB) EN |
View or download |
