Product Overview
KEMET’s epoxy molded radial through-hole ceramic capacitors in X7R dielectric feature an 125°C maximum operating temperature and are considered “temperature stable.” The Electronics Industries Alliance (EIA) characterizes X7R dielectric as a Class II material. Components of this classification are fixed, ceramic dielectric capacitors suited for bypass and decoupling applications or for frequency discriminating circuits where Q and stability of capacitance characteristics are not critical. X7R exhibits a predictable change in capacitance with respect to time and voltage and boasts a minimal change in capacitance with reference to ambient temperature. Capacitance change is limited to ±15% from −55°C to +125°C.
- Radial through-hole form factor
- Molded case
- Non-polar device, minimizing installation concerns
- SnPb-plated lead finish (60/40)
Product details
| Capacitance |
0.1µF |
| Capacitance Tolerance |
± 10% |
| Dielectric Characteristic |
X7R |
| Capacitor Case / Package |
Radial Leaded |
| Product Diameter |
- |
| Product Width |
2.29mm |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
| Voltage(DC) |
50V |
| Capacitor Terminals |
Radial Leaded |
| Lead Spacing |
5.08mm |
| Product Range |
C052C LDD Comm Series |
| Product Length |
4.83mm |
| Product Height |
4.83mm |
| Operating Temperature Max |
125°C |
| SVHC |
Lead (04-Feb-2026) |
Other details
| Brand |
KEMET |
| Part Number |
C052C104K5R5CA |
| Quantity |
Each |
