Product Overview
TRACO POWER TVN 3-2410 Isolated Through Hole DC/DC Converter, ITE, SIP, 2:1, 3 W, 1 Output, 3.3 V
Product details
| Power Supply Applications |
ITE |
| Input Ratio |
2:1 |
| No. of Outputs |
1 Output |
| Output Current - Output 1 |
700mA |
| Output Current - Output 2 |
- |
| Isolation Voltage |
1.6kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
11.2mm |
| Input Voltage DC Min |
18V |
| Product Range |
TVN 3 Series |
| DC / DC Converter Type |
SIP |
| Output Power Max |
3W |
| Output Voltage - Output 1 |
3.3V |
| Output Voltage - Output 2 |
- |
| Output Regulation |
Regulated |
| Input Voltage DC Nom |
24V |
| Width |
9.6mm |
| Depth |
21.8mm |
| Input Voltage DC Max |
36V |
| SVHC |
Lead (04-Feb-2026) |
Other details
| Brand |
TRACO POWER |
| Part Number |
TVN 3-2410 |
| Quantity |
Each |
