Product Overview
WURTH ELEKTRONIK 820527501 TVS Varistor, 75 V, 100 V, WE-VD, 200 V, Disc 20mm, Metal Oxide Varistor (MOV)
Product details
| Voltage Rating VAC |
75V |
| Product Range |
WE-VD |
| Varistor Case Style |
Disc 20mm |
| Peak Surge Current @ 8/20µs |
6.5kA |
| Operating Temperature Max |
85°C |
| Automotive Qualification Standard |
- |
| Voltage Rating VDC |
100V |
| Clamping Voltage Vc Max |
200V |
| Varistor Type |
Metal Oxide Varistor (MOV) |
| Operating Temperature Min |
-40°C |
| Peak Energy (10/1000uS) |
64J |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
WURTH ELEKTRONIK |
| Part Number |
820527501 |
| Quantity |
Each |
| Technical Data Sheet (1.14MB) EN |
View or download |
| Product Change Notice (135.04KB) EN |
View or download |
