Product Overview
Wurth Electronics SMD High Current Inductor with PQ Core (MnZn), WE-HCF, series is offered in flat wire package sizes 2013, 2818, and 2815 and has been extended to include Litz and round wire versions in 2920 package size. The WE-HCF series has a saturation current up to 125A and inductance values ranging from 0.7µH to 680µH. The Litz and round wire versions feature a plastic base for better coplanarity and mechanical stability.
- Saturation current up to 125A
- Flat, round and litz wire version to optimize DC & AC Losses
- Inductance values ranging from 0.7µH to 680µH
- Low core losses (MnZn)
- Magnetically shielded
- Litz and round wire: base for SMD mount and complanarity
- Operating temperature: -40°C to +125°C
Product details
| Inductance |
3.3µH |
| Inductor Construction |
Shielded |
| Product Range |
WE-HCF Series |
| DC Resistance Max |
1310µohm |
| Product Length |
27mm |
| Product Height |
15.4mm |
| RMS Current (Irms) |
36A |
| Saturation Current (Isat) |
60.5A |
| Inductor Case / Package |
- |
| Inductance Tolerance |
± 15% |
| Product Width |
28mm |
| SVHC |
No SVHC (04-Feb-2026) |
