Product Overview
TDK-LAMBDA CCG30-48-12S Isolated Through Hole DC/DC Converter, ITE, DIP, 4:1, 30 W, 1 Output, 12 V
Product details
| Power Supply Applications |
ITE |
| Input Ratio |
4:1 |
| No. of Outputs |
1 Output |
| Output Current - Output 1 |
2.5A |
| Output Current - Output 2 |
1A |
| Isolation Voltage |
1.5kV |
| DC / DC Converter Output Type |
Fixed, Adjustable |
| Height |
9.9mm |
| Input Voltage DC Min |
18V |
| Product Range |
CCG30 Series |
| DC / DC Converter Type |
DIP |
| Output Power Max |
30W |
| Output Voltage - Output 1 |
12V |
| Output Voltage - Output 2 |
-15V |
| Output Regulation |
- |
| Input Voltage DC Nom |
48V |
| Width |
25.4mm |
| Depth |
25.4mm |
| Input Voltage DC Max |
76V |
| SVHC |
Lead (17-Jan-2023) |
Other details
