Description
Product Overview
The 31059104 is a 4-pole screw type metallic Terminal Block with solderable and wire protector, fittable without loss of poles. Direction of connection in 90° angle. Terminal body is made of CuZn with Ni + Sn surface.
- IP20 Protection rating (according to IEC 529)
- 22 to 16AWG wire size
- M2 Screw thread
- PA66 insulator
- V0 Flammability class
Applications
Industrial
Product details
| Pitch Spacing | 3.5mm |
| Wire Size AWG Min | 28AWG |
| Conductor Area CSA | 1mm² |
| Rated Current | 13.5A |
| Block Orientation | Through Hole Right Angle |
| SVHC | No SVHC (25-Jun-2025) |
| No. of Positions | 4Ways |
| Wire Size AWG Max | 16AWG |
| Wire Connection Method | Screw |
| Rated Voltage | 125V |
| Product Range | - |
Other details
| Brand | METZ CONNECT |
| Part Number | 31059104 |
| Quantity | Each |
| Manufacturer Catalogue (1.29MB) EN | View or download |
