| ₹ 1426.85 includes GST and import duties. | |
| B2B customers can avail ₹ 217.59 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
The S25FL512SAGMFIG11 is a Flash Non-volatile Memory connects to a host system via a serial peripheral interface. Traditional SPI single bit serial input and output is supported as well as optional two bit and four bit serial commands. This multiple width interface is called SPI Multi-I/O or MIO. In addition, the FL-S family adds support for double data rate read commands for SIO, DIO and QIO that transfer address and read data on both edges of the clock. The eclipse architecture features a page programming buffer that allows up to 256 words to be programmed in one operation, resulting in faster effective programming and erase than prior generation SPI program or erase algorithms.
- SPI clock polarity and phase modes 0 and 3
- Common flash interface (CFI) data for configuration information
- Programming (1.5Mbytes/s)
- Erase (0.5 to 0.65Mbytes/s)
- 100000 Program-erase cycles on any sector typical
- 20-year Typical data retention
Applications
Computers & Computer Peripherals
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Flash Memory Type | Serial NOR |
| Memory Configuration | 64M x 8bit |
| IC Case / Package | SOIC |
| Clock Frequency Max | 133MHz |
| Supply Voltage Min | 2.7V |
| Supply Voltage Nom | - |
| Operating Temperature Min | -40°C |
| Product Range | 3V Serial NOR Flash Memories |
| SVHC | No SVHC (25-Jun-2025) |
| Memory Density | 512Mbit |
| Interfaces | SPI |
| No. of Pins | 16Pins |
| Access Time | - |
| Supply Voltage Max | 3.6V |
| IC Mounting | Surface Mount |
| Operating Temperature Max | 85°C |
| MSL | MSL 3 - 168 hours |
Other details
| Brand | INFINEON |
| Part Number | S25FL512SAGMFIG11.. |
| Quantity | Each |
| Technical Data Sheet (1.63MB) EN | View or download |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1398.31 |
| 3-5 | ₹ 1384.04 |
| 5-10 | ₹ 1355.51 |
| 10+ | ₹ 1326.97 |
Bulk discount will be automatically applied during checkout based on quantity.
