Description
Product Overview
The 1N5820G is an axial-leaded Schottky Barrier Rectifier with moulded epoxy case, all external surfaces corrosion-resistant and terminal leads are readily solderable finish. This series employs the Schottky barrier principle in a large area metal-to-silicon power diode. State-of-the-art geometry features chrome barrier metal, epitaxial construction with oxide passivation and metal overlap contact. Ideally suited for use as rectifiers in low-voltage, high-frequency inverters, free wheeling diodes and polarity protection diodes.
- Extremely low forward voltage
- Low power loss/high efficiency
- Low stored charge and majority carrier conduction
- 24V Non-repetitive peak reverse voltage
- 14V RMS reverse voltage
- 28°C/W Junction-to-ambient thermal resistance
Applications
Power Management
Product details
| Repetitive Peak Reverse Voltage | 20V |
| Diode Configuration | Single |
| No. of Pins | 2Pins |
| Forward Surge Current | 80A |
| Diode Mounting | Through Hole |
| Qualification | - |
| Average Forward Current | 3A |
| Diode Case Style | DO-201AD |
| Forward Voltage Max | 475mV |
| Operating Temperature Max | 125°C |
| Product Range | 1N5820 |
| SVHC | Lead (25-Jun-2025) |
Other details
| Brand | ONSEMI |
| Part Number | 1N5820G |
| Quantity | Each |
| Product Change Notice (191.72KB) EN | View or download |
| Technical Data Sheet (183.90KB) EN | View or download |
