Description
Product Overview
The SS460S is a high-sensitivity bipolar latching digital hall-effect Sensor IC, small, sensitive and versatile devices that are operated by the magnetic field from a permanent magnet or an electromagnet. This is designed to respond to alternating North and South poles. The SS360NT is turned ON by a North pole while the SS360ST and SS460S are turned ON by a South pole. The high-sensitivity bipolar latching digital hall-effect sensor IC offers reliable switching points with a high magnetic sensitivity of 30G typical (55G maximum). This sensor IC does not use chopper stabilization on the Hall element, providing a clean output signal and a faster latch response time when compared to competitive high sensitivity Hall-effect bipolar latching sensor ICs which do use chopper stabilization.
- Fastest response time in its class, provides more efficiency in commutating a brushless DC motor
- No chopper stabilization, results in a clean output signal
- High sensitivity
- Bipolar latching magnetic
- Wide operating voltage range, allows for potential use in a wide range of applications
- Built-in reverse voltage, enhances the protection of the sensor and the circuits
- Durable design, allows operation up to 150°C (302°F)
Applications
Industrial, Commercial, Motor Drive & Control, Sensing & Instrumentation, Metering, Robotics, Logistics, Medical
Warnings
ESD sensitive device, take proper precaution while handling the device.
Product details
| Hall Effect Type | Latching |
| Output Current | 20mA |
| Sensor Case Style | TO-92 |
| Supply Voltage Max | 24V |
| Operating Temperature Max | 150°C |
| Qualification | - |
| Sensor Case / Package | TO-92 |
| No. of Pins | 3Pins |
| Supply Voltage Min | 3V |
| Operating Temperature Min | -40°C |
| Product Range | - |
Other details
| Brand | HONEYWELL |
| Part Number | SS460S |
| Quantity | Each |
| Operating Instructions (685.93KB) EN | View or download |
| Technical Data Sheet (1002.18KB) EN | View or download |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
