Description
Product Overview
The 56050C is a 10A Current Sensing Transformer, designed to monitor AC currents. This can be used for high frequency current sensing, for example in switched-mode power supplies, motor control and electronic lighting ballasts.
- 20 to 200kHz Frequency Range
- Centre Tapped Variants are Available
- 300°C for 10s Peak Wave Solder Temperature
Applications
Sensing & Instrumentation
Product details
| Turns Ratio | 1:50 |
| Primary Current | 10A |
| Frequency Range | 20kHz to 200kHz |
| DC Resistance Primary | 0.133ohm |
| Transformer Terminals | PC Pin |
| SVHC | No SVHC (04-Feb-2026) |
| Inductance | 9.3mH |
| ET Constant | - |
| DC Resistance Secondary | 0.199ohm |
| Transformer Mounting | Through Hole |
| Product Range | 56050C Series |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | 56050C |
| Quantity | Each |
| Product Change Notice (159.78KB) EN | View or download |
| Technical Data Sheet (93.66KB) EN | View or download |
