| ₹ 308.49 includes GST and import duties. | |
| B2B customers can avail ₹ 47.04 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
The VT2045BP-M3/4W is a Trench MOS Barrier Schottky Rectifier with matte tin-plated terminals. It is suitable for use in solar cell junction box as a bypass diode for protection, using DC forward current without reverse bias.
- Low forward-voltage drop, low power losses
- High efficiency operation
- Halogen-free
- UL94V-0 Flammability rating
- 275°C/10-second Maximum solder dip temperature as per JESD 22-B106
Applications
Power Management, Commercial, Industrial
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Repetitive Peak Reverse Voltage | 45V |
| Diode Configuration | Single |
| No. of Pins | 2Pins |
| Forward Surge Current | 160A |
| Diode Mounting | Through Hole |
| Qualification | - |
| Average Forward Current | 20A |
| Diode Case Style | TO-220AC |
| Forward Voltage Max | 660mV |
| Operating Temperature Max | 150°C |
| Product Range | VT204 |
| SVHC | Lead (04-Feb-2026) |
Other details
| Brand | VISHAY |
| Part Number | VT2045BP-M3/4W |
| Quantity | Each |
| Product Change Notice (287.97KB) EN | View or download |
| Technical Data Sheet (133.00B) EN | View or download |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 302.32 |
| 3-5 | ₹ 299.24 |
| 5-10 | ₹ 293.07 |
| 10+ | ₹ 286.9 |
Bulk discount will be automatically applied during checkout based on quantity.
